SWITCH/BLIND RELAY, 2/4 GANG FUTURE LINEAR SBA-F-2.1.1

Product Code: AB-SBA-F-2.1.1

Brand
ABB FREE@HOME
RRP $306.00


Quantity In Cart: 0
Unit of Measure
EACH



Technical Specifications
Brands ABB-free@home

For controlling blind or awning motors. With integrated blind actuator. Blind function is available also without prior programming (left sensor channel is pre-configured). Configuration can be changed later via the web interface (groups, scenes, etc.). The right sensor channel for programming additional functions (groups, scenes, etc.). For contacting 2gang rocker 6230-2x-xxx, 6231-2x-xxx, 6232-2x-xxx, 6233-2x-xxx and 6234-2x-xxx. The bus can be connected via enclosed terminal block. When installing in the flush-mounted box, a spatial division between the bus cable and 127 V/230 V installation cable is to be adhered to! If this minimum distance is not possible, use electronic boxes or insulating tubes.

Installation
  • Mounting Type: Flush Mounted
Environmental
  • Ambient Air Temperature: Operation -5 ... +45 °C
  • Degree of Protection: IP20
Technical
  • Number of Outputs: 2
  • Number of Inputs: 1
  • Compatible Bus Systems: free@home (TP)
  • Product Range: free@home
  • Transmission Standard: Twisted Pair Wiring
  • Terminal Type: Bus Connection
Electrical
  • Current Type: AC
  • Rated Current (In): 4 A
  • Maximum Switching Current: Resistive Load 4 A
  • Maximum Switching Power: 920 W
  • Load Type: Electrical Drives
Dimensions
  • Product Net Width: 71 mm
  • Product Net Height: 71 mm
  • Product Net Depth / Length: 43 mm
  • Product Net Weight: 89 g
  • Built-In Depth (t2): 32 mm
